Gravel Stabilizer Hdpe Geo Cell Manufacturer Price Geocell Ground Grid

Geocell is a kind of using high density polyethylene (HDPE) and ultrasonic technology joint welded together 3d mesh structure, ensure the consistency of slope erosion resistance, more durable performance, flexible packaging and transportation has a wide range of cell size and depth, to meet your projects and civil engineering application requirements.
Availability:
Quantity:
  • Geocell

  • Zhongloo

Product introduction



Plastic HDPE geocell is three dimensional, honeycomb like structures manufactured from high density polyethylene and jointly welded by ultrasonic technique. It is flexible to fold during the transport and installation on construction site. The geocell nets will be filled with soils, granular, cements or other on-site infill materials when stretched into web structures, which has powerful and rigid confinement in the lateral and vertical sides.

Technical parameter:


Geocell
item
PP
PE
tensile strength of Strip ≥(Mpa)
23
20
Tensile strength of weld ≥(N/cm)
100
100
Tensile strength of cell edge ≥(N/cm)
200
200
Intermediate tensile strength of cell sheet ≥(N/cm)
120
120

Application

Load Support

Geocell is a confinement system that performs better than conventional crushed stone sections, and it provides an expedient construction technique for access roads over soft ground without being adversely affected by wet weather conditions. It can also be used to strengthen paved areas.

Retaining Wall

GeoCell can be used for both cut and fill applications on retaining walls. The flexible HDPE panels are custom made to the front to back dimensions required by the project engineer. GeoCell can be easily installed around curves, pipes or other structures. The panels are constructed with the front facing strip colored green or tan to blend in with the surroundings. GeoCell panels can be stacked to create a 90 degree wall, or they can be stair stepped at every layer to create exposed cell for vegetation.
