Factory Direct Popular Polpropylene Dewatering Bag Geotube for Lake Desilting And Water Purification

1. High strength, low deformation geotube geotube

2. Durability: steady property, not easy to resolved, air slaked and can keep the original property long term

3. Anti-erosion: anti-acid, anti-alkali, resists insects and mould geotube

4. Permeability: could control the sieve size to retain certain permeability geotube

Color:
Widt:
Length:
Material:
Name:
Size:
Weight:
Availability:
Quantity:
  • TGGD

1.Product DescriptionIMG_1449 SUMMER 孟丽

Geotube is one of the most effective components that are most usually used in protective structure of waterproof erosion. Soft mattress is covered to the places where water flows to reduce the impact energy of water flow and protect soil particles from being flown away by water flow by means of its filtration function, thus, ensuring the stability of soil mass.
The list of materials that have been dewatered by geotextile tubes includes, but is not limited to: municipal water treatment and wastewater sludge, contaminated dredged material, agricultural animal waste and fine-grained, inorganic industrial sludge and shale gas fracking. For shoreline protection applications, the geotextile tube is filled with structural material such as beach or river sand.


2.Product Feature

1). High strength, low deformation geotube geotube

2). Durability: steady property, not easy to resolved, air slaked and can keep the original property long term

3). Anti-erosion: anti-acid, anti-alkali, resists insects and mould geotube

4). Permeability: could control the sieve size to retain certain permeability geotube

5).Effective high volume containment

6).Efficient dewatering and volume reduction

7).Cost effective

8).No special equipment required



3.Product Parameter

Geotextile tube for Coastal protection & Dewatering
Item

Test Standard
Unit
Technical Data
Material



Polypropylene With Black or Sand Color
Spec



HT50
HT70
HT90
HT105
HT120
HT200
Tensile Strength
MD
ASTM D4595
KN/M
50
70
90
105
120
200
CD
ASTM D4595
KN/M
50
95
120
105
120
200
Elongation
MD/CD
ASTM D4595
%
10,11,12,13,15
Opening Size O90
mm
0.05-0.90 or Customized
Length
m
20,30,50,100m
Circumference
m
5-20m


4.Project Cases

1).Solid dam engineering
2).Protective structure of waterproof erosion
3).Protect soft mattress from being floated up or moves by water flow

4).Soft soil improvement

5).Slope protectionphotobank (1)photobank (2)photobank
