1. Corrosion resistance
2. good water resistance
3. Long lasting
4. Specifications can be customized
| Color: | |
|---|---|
| Model Number: | |
| Thickness: | |
| Width: | |
| Length: | |
| Package: | |
| Standard: | |
| Quantity: | |
geomembrane
zhongloo
geomembrane
Ted Bakerblue Lagoon Hdpe Geomembrane Pond Liner Price Geomembrane Factory
Products Description
Our high density polyethylene (HDPE) geomembranes provide an impermeable barrier against a wide range of solids and liquids. They exhibit excellent chemical and UV resistance,impermeability, and high yield and welded seam strengths, which is widely used as the liner.(model according to the thickness of distinction, different thickness and different price) production capacity: thickness:0.1 mm -6 mm, width: 1-8 meters. It is suitable for seepage control in special industries, and is widely used for aquaculture, seepage control, reservoirs or sewage treatment ponds.
1) Good physical and mechanic performance
2) High tearing resistance, strong deformation adaptability
3) Puncture-resisting, aging resisting, ultra-violet radiation, oil and salt, and corrosion resistance
4) Good adaptability to high and low temperature, non-toxicity, long service life
5) Good waterproof, drainage, anti-seepage and damp proof effects
6) Complete width and thickness specifications, low cost and easy installation.
| Geomembrane Technical Parameter (GB standard) | |||||||
| Spec Properties | GMS0.5 | GMS0.75 | GMS1.0 | GMS1.25 | GMS1.5 | GMS2.0 | GMS2.5 |
| Thickness | 0.5mm | 0.75mm | 1.0mm | 1.25mm | 1.5mm | 2.0mm | 2.5mm |
| Tensile Properties (each direction) (≥) .yield strength .break strength .yield elongation .break elongation | 7KN/m 10KN/m -- 600% | 10KN/m 15KN/m -- 600% | 13KN/m 20KN/m 11% 600% | 16KN/m 25KN/m 11% 600% | 20KN/m 30KN/m 11% 600% | 26KN/m 40KN/m 11% 600% | 33KN/m 50KN/m 11% 600% |
| Density(≥) | 0.940g/cc | 0.940g/cc | 0.940g/cc | 0.940g/cc | 0.940g/cc | 0.940g/cc | 0.940g/cc |
| Puncture Restistance (≥) | 120N | 180N | 240N | 300N | 360N | 480N | 600N |
| Carbon Black Content | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% |
| Carbon black Dispersion | Noted(1) | Noted(1) | Noted(1) | Noted(1) | Noted(1) | Noted(1) | Noted(1) |
| Tear Resistance (≥) | 56N | 84N | 115N | 140N | 170N | 2255N | 280N |
| Oxidative Induction Time(OIT) Standare OIT(≥) | 60min. | 60min. | 60min. | 60min. | 60min. | 60min. | 60min. |
Environmental protection, environmental hygiene (such as garbage landfill site, treatment of sewage, containment of poisonous or harmful wastes, hazardous warehouse, industry wastes, construction & explosive rubbish, etc).
Water conservancy (such as waterproofing, stopping up leak, reinforcement for lake, river, channels, tunnels, dams and reservoirs; vertical wall with core, slope protection, etc.
Municipal engineering (expressway, subway, underground engineering of building; and liner of roof pool, roof garden's waterproofing, sewage channel, etc)
Garden (backing & slope protection of artificial lake, pool, golf course's pond.
Petrochemicals (liner secondary lining of chemical reeaction tank and deposit tank from chemical plant & refinery; seepage control of oil tank from gas station
Mining (backing seepage of washing pond, heap leaching pond, ashery, dissolved pond, deposit pond from the stack and tailing.
Traffic facilities (highway foundation reinforcement, culvert stopping up leak
Agriculture (stolling up leak for reservoirs, drinking pools, storage ponds and irrigation system.
Aquaculture industry (seepage control for sea cucumber circle's slope protection, liner of fish pool & shrimp pond.
Seepage, corrosion, leaks control & reinforcement for other facility, leachate collection.
Temporary container structure, prefabrication of special parts.
Core Features of Geomembrane Liner
Excellent Anti-seepage Performance: With an anti-seepage coefficient as high as 1×10⁻¹⁷ cm/s, it provides long-lasting and reliable seepage protection.
Outstanding Mechanical Strength: High tensile strength and tear resistance ensure the stability of engineering structures.
Superior Flexibility and Elasticity: Excellent flexibility and elasticity enable it to adapt to uneven foundation settlement.
Strong Corrosion Resistance: Resistant to strong acids, alkalis, and oil corrosion, offering excellent chemical stability.
Wide Temperature Adaptability: Excellent heat and cold resistance, suitable for various climatic conditions.
Exceptional Durability and Anti-aging: Strong UV radiation resistance and excellent anti-aging performance.
Safe and Eco-friendly Material: Made from high-quality virgin plastic and carbon black particles, containing no stabilizers, harmless to the environment.
Convenient and Efficient Installation: Excellent weldability makes installation and construction simple and efficient.
Cost-effective Choice: Outstanding comprehensive performance delivers excellent economic benefits.
Authoritative International Certification: Products are CE certified, compliant with EU standards, ensuring internationally aligned quality.
