Virgin ASTM Anti-Seepage Waterproof Impermeable Smooth Textured HDPE LDPE LLDPE PVC Geomembrane for Dam Pond Liner Landfill Mining

What is Geomembrane?
A geomembrane is very low permeability synthetic membrane liner or barrier used with any

geotechnical engineering related material so as to control fluid (liquid or gas) migration in a

human-made project structure or system.

Main Features of HDPE Geomembrane:
1.Excellent anti-seepage performance geomembrane has extremely low permeability and can effectively prevent the penetration of water and other liquids, thereby preventing seepage.
2.Good durability geomembrane has good anti-aging properties and chemical stability, and can be used for a long time in various harsh environments.
3.Convenient construction geomembrane has high flexibility and ductility, is easy to lay and connect, and construction is convenient and fast.
4.Economical and affordable geomembrane has a relatively low cost, long service life, low maintenance costs, and high cost performance.

Product Parameters

ASTM GM13 HDPE Geomembrane - Smooth
Properties	Test Method (ASTM)	Test Value
		0.75 mm	1.00 mm	1.25 mm	1.50 mm	2.00 mm	2.50mm	3.00mm
Density	D 792	0.940 g/cm³	0.940 g/cm³	0.940 g/cm³	0.940 g/cm³	0.940 g/cm³	0.940 g/cm³	0.940 g/cm³
Tensile properties Yield strength  N/mm Break strength  N/mm Yield elongation  % Break elongation  %	D6693 Type IV	11 20 12 700	15 27 12 700	18 33 12 700	22 40 12 700	29 53 12 700	37 67 12 700	44 80 12 700
Tear Resistance	D 1004	93 N	125 N	156 N	187 N	249 N	311N	374N
Puncture Resistance	D 4833	240 N	320 N	400 N	480 N	640 N	800N	960N
Stress Crack Resistance	D 5397	500 hr.	500 hr.	500hr.	500hr.	500 hr.	500 hr.	500 hr.
Carbon Black Content Carbon black content(range) Carbon black dispersion	D 1603 D 5596	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%
		Carbon black dispersion(only near spherical agglomerates) for 10 different views:9 in categories l or 2 and 1 in category 3.
Oxidative Induction Time (OIT) Standard OIT High Pressure OIT	D 3895 D 5885	100 min.	100 min.	100 min.	100 min.	100 min.	100 min.	100 min.
		400 min.	400 min.	400 min.	400 min.	400 min.	400 min.	400 min.
Oven Aging at 85°C Standard OIT  retained after 90 days High Pressure OIT retained after 90 days	D 5721 D 3895 D 3895	55%	55%	55%	55%	55%	55%	55%
		80%	80%	80%	80%	80%	80%	80%
UV Resistance Standard OIT High Pressure OIT	D 3895 D 5885	50%	50%	50%	50%	50%	50%	50%
		50%	50%	50%	50%	50%	50%	50%
