| Material: | |
|---|---|
| Width: | |
| Length: | |
| Quantity: | |
ZL-TGB
zhongloo
Polypropylene non woven geotextile is made from high-strength polypropylene short fiber by non woven needle punched manufacturing process. It has separation, filtration, drainage, reinforcement, protection and maintenance etc. PET non-woven geotextile is made from PP short fiber by non-woven needle punched manufacturing process, it has isolation,filtration, drainage, reinforcement, protection and maintenance function.
High Strength
Offers superior tensile strength in all directions, outperforming other needle-punched nonwoven fabrics of the same weight.
UV Resistance
Highly resistant to ultraviolet (UV) degradation, ensuring long-term performance in exposed applications.
Extreme Temperature Resistance
Maintains structural integrity at temperatures up to 230°C, suitable for a wide range of environments.
Excellent Permeability & Drainage
The thick, needle-punched structure enables efficient in-plane drainage and high vertical water permeability.
Creep & Chemical Resistance
Outstanding resistance to creep deformation, soil chemicals, and fuel corrosion ensures long-term stability and durability.
High Ductility
Exhibits excellent elongation under stress, allowing it to conform to uneven or irregular surfaces without compromising performance.
| Non-woven Geotextile Technical Parameter (GB standard) | |||||||||
| Item | unit | Standard Specification | |||||||
| 100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | ||
| Thickness≥ | mm | 0.9 | 1.3 | 1.7 | 2.1 | 2.4 | 2.7 | 3 | 3.3 |
| width Deciation | % | 0.5 | |||||||
| Breaking strength | KN/M | 2.50 | 4.50 | 6.50 | 8.00 | 9.50 | 11.00 | 12.50 | 14.00 |
| Breaking Elongation | % | 25-100 | |||||||
| Weight Tolerance | g/m² | -8 | -8 | -8 | -8 | -7 | -7 | -7 | -7 |
| CBR Tear Strength≥ | KN | 0.3 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 |
| Tear Strength≥ | KN | 0.08 | 0.12 | 0.16 | 0.2 | 0.24 | 0.28 | 0.33 | 0.38 |
| Vertical Permeability | N/5cm | Kx(10﹣¹-10﹣³) | |||||||
| EOS 090 | mm | 0.07-0.2 | |||||||
1) Anti-aging, the product has very high anti-ultraviolet radiation ability, not easy to degradation.
2) High temperature resistance to up to 230ºC maintaining structure stability and original physical properties.
3) High flat drainage and vertical permeability.
4) High creep resistance
5) Resistance of erosion of chemicals in soil as well as the corrosion of gasoline and diesel etc.
6) High elongation under certain stress, thus able to adapt to uneven and irregular bases.
Q：Can you send samples?
A：Yes，we are very happy to provide you with free samples to check the quality of our products.
Q：Are you a manufacturer or a trading company?
A：Our company located in Hefei，Anhui Province，with are gistered capital of 52 miion yuan.It is a professiona lmanufacturer of geomembrane，geotextile，geogrid and other products.So we have the competitive price with best quality.
Q：Can you produce the product according to customers' requirements?
A: Sure，we are professional manufacturer，OEM and ODM are both welcome.
Q：How long is the delivery time?
A: General within 3-7days after received the deposit.
Q: How to control product quality?
A: Our factory adopts lean management，products from the beginning to the end of the production process have strict quality control.All products must be strictly tested before packing and shipping.
Polypropylene non woven geotextile is made from high-strength polypropylene short fiber by non woven needle punched manufacturing process. It has separation, filtration, drainage, reinforcement, protection and maintenance etc. PET non-woven geotextile is made from PP short fiber by non-woven needle punched manufacturing process, it has isolation,filtration, drainage, reinforcement, protection and maintenance function.
High Strength
Offers superior tensile strength in all directions, outperforming other needle-punched nonwoven fabrics of the same weight.
UV Resistance
Highly resistant to ultraviolet (UV) degradation, ensuring long-term performance in exposed applications.
Extreme Temperature Resistance
Maintains structural integrity at temperatures up to 230°C, suitable for a wide range of environments.
Excellent Permeability & Drainage
The thick, needle-punched structure enables efficient in-plane drainage and high vertical water permeability.
Creep & Chemical Resistance
Outstanding resistance to creep deformation, soil chemicals, and fuel corrosion ensures long-term stability and durability.
High Ductility
Exhibits excellent elongation under stress, allowing it to conform to uneven or irregular surfaces without compromising performance.
| Non-woven Geotextile Technical Parameter (GB standard) | |||||||||
| Item | unit | Standard Specification | |||||||
| 100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | ||
| Thickness≥ | mm | 0.9 | 1.3 | 1.7 | 2.1 | 2.4 | 2.7 | 3 | 3.3 |
| width Deciation | % | 0.5 | |||||||
| Breaking strength | KN/M | 2.50 | 4.50 | 6.50 | 8.00 | 9.50 | 11.00 | 12.50 | 14.00 |
| Breaking Elongation | % | 25-100 | |||||||
| Weight Tolerance | g/m² | -8 | -8 | -8 | -8 | -7 | -7 | -7 | -7 |
| CBR Tear Strength≥ | KN | 0.3 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 |
| Tear Strength≥ | KN | 0.08 | 0.12 | 0.16 | 0.2 | 0.24 | 0.28 | 0.33 | 0.38 |
| Vertical Permeability | N/5cm | Kx(10﹣¹-10﹣³) | |||||||
| EOS 090 | mm | 0.07-0.2 | |||||||
1) Anti-aging, the product has very high anti-ultraviolet radiation ability, not easy to degradation.
2) High temperature resistance to up to 230ºC maintaining structure stability and original physical properties.
3) High flat drainage and vertical permeability.
4) High creep resistance
5) Resistance of erosion of chemicals in soil as well as the corrosion of gasoline and diesel etc.
6) High elongation under certain stress, thus able to adapt to uneven and irregular bases.
Q：Can you send samples?
A：Yes，we are very happy to provide you with free samples to check the quality of our products.
Q：Are you a manufacturer or a trading company?
A：Our company located in Hefei，Anhui Province，with are gistered capital of 52 miion yuan.It is a professiona lmanufacturer of geomembrane，geotextile，geogrid and other products.So we have the competitive price with best quality.
Q：Can you produce the product according to customers' requirements?
A: Sure，we are professional manufacturer，OEM and ODM are both welcome.
Q：How long is the delivery time?
A: General within 3-7days after received the deposit.
Q: How to control product quality?
A: Our factory adopts lean management，products from the beginning to the end of the production process have strict quality control.All products must be strictly tested before packing and shipping.
