Cheap Price Plastic Fence Geogrid Mesh Soil Stabilization Biaxial Geogrid For Kenya

1. High Tear Strength
2. Flexible and durable
3. Excellent Creep Resistance
4. UV resistance
5. Cost effective

Type:
Warranty:
Model Number:
Raw material:
Feature:
Width:
function:
Availability:
Quantity:
  • 35KN 50KN 80KN 100KN 150KN 180KN 200KN 300KN

  • Zhongloo

Cheap Price Plastic Fence Geogrid Mesh Soil Stabilization Biaxial Geogrid For Kenya

1.Product Parameter

Biaxial geogrid
item Specification
Type TGSG1515 TGSG2020 TGSG2525 TGSG3030 TGSG3535 TGSG
4040
TGSG
4545
TGSG5050
Vertical and horizontal tensile strength≥(KN/M) 15 20 25 30 35 40 45 50
Tensile strength at 2% elongation≥(KN/M) 5 7 9 10.5 12 0.14 16 17.5
Tensile strength at 5% elongation≥(KN/M) 7 14 17 21 24 28 32 35
Maximum elongation≤(%) 15


2.Product Description

  1. A geogrid is a geosynthetic with large openings or apertures.

  2. Plastic Geogrids are used as soil reinforcement below roads, under structures and behind retaining walls.

  3. Biaxial Geogrid also reinforce paving overlays. Geogrids can be uniaxial (strength in one direction) or biaxial (equal strength in both directions) and are made from polyester, polypropylene or fiberglass.

  4. Manufacturing methods include woven, knitted, extruded or otherwise "integrally formed”.


3. Product Application:

Soft foundation reinforcing for highway, railway, Slop protecting projects, landfill side

Function:

  • Improve the bearing capacity of foundation;

  • Preventing cracking and subsiding;

  • Convenient to construct, reducing cost and maintaining expense


4.Project Cases

  1. Road surface asphalt overlay construction engineering; Asphalt layers reinforcement

  2. Converting old cement concrete road into composite road; Restraining reflection cracking caused by block shrinkage.

  3. Road extension; Preventing and controlling the cracking caused by new and old combination and uneven settlement.

  4. Treatment of the conjunction between tunnel and bridge or foundation.


Plastic geogridHighest Tensile Strength Plastic PP Biaxial GeogridPlastic Biaxial Geogrid
