0.3mm 0.5mm 0.75mm 1.0mm 1.5mm 2.0mm Geomembrane HDPE/LDPE /LLDPE Geosynthetics Waterproof Product

HDPE Geomembrane Technical Parameter (GB standard)
Spec Properties	GMS0.5	GMS0.75	GMS1.0	GMS1.25	GMS1.5	GMS2.0	GMS2.5
Thickness	0.5mm	0.75mm	1.0mm	1.25mm	1.5mm	2.0mm	2.5mm
Tensile Properties (each direction) (≥) .yield strength .break strength .yield elongation .break elongation	7KN/m 10KN/m -- 600%	10KN/m 15KN/m -- 600%	13KN/m 20KN/m 11% 600%	16KN/m 25KN/m 11% 600%	20KN/m 30KN/m 11% 600%	26KN/m 40KN/m 11% 600%	33KN/m 50KN/m 11% 600%
Density(≥)	0.940g/cc	0.940g/cc	0.940g/cc	0.940g/cc	0.940g/cc	0.940g/cc	0.940g/cc
Puncture Restistance (≥)	120N	180N	240N	300N	360N	480N	600N
Carbon Black Content	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%
Carbon black Dispersion	Noted(1)	Noted(1)	Noted(1)	Noted(1)	Noted(1)	Noted(1)	Noted(1)
Tear Resistance (≥)	56N	84N	115N	140N	170N	2255N	280N
Oxidative Induction Time(OIT) Standare OIT(≥)	60min.	60min.	60min.	60min.	60min.	60min.	60min.

Basic Details
Geomembrane; pond liner
1.Main Thickness:0.1mm,0.2mm,0.3mm,0.5mm, 0.75mm,1.0mm,1.5mm,2.0mm,3.0mm,4.0mm,5.0mm
2.Main Width:4m, 5m, 5.8m, 6.0m, 7m, 8m,10m
3.Main Length:50m/100m
4.Main Color: black, white, blue, green
5. Optional surface: Textured or Smooth surface.
6.Material:HDPE, LDPE,LLDPE,EVA
7. Certificate & Test: ISO, TUV,SGS
8. Quality Control: Third party test and factory lab test

The polyethylene geomembrane is made of high-quality polyethylene virgin resin,the main component is 97.5% polyethylene,2.5% carbon black,anti-aging agent,antioxidant,ultraviolet absorber,stabilizer and other additives, using internationally advanced mutiple layer co-extrusion blow molding process or muti-head flat extrusion process.The finished product has excellent resistance to chemical acid and alkali,UV resistance, strength, durability and stress tear resistance.

Characteristics:
1. Good flexibility
2. For service temperature range:-70°C~110°C
3. Corrosion resistance, aging resistance
4. Excellent environmental stress cracking resistance property
5. High tensile strength and elongation

1. Good flexibility
2. For service temperature range:-70°C~110°C
3. Corrosion resistance, aging resistance
4. Excellent environmental stress cracking resistance property

5. High tensile strength and elongation
